Metal 52 ac

Metal 52 ac

$160.65 CAD
Metal 52 ac

Metal 52 ac

RBMetalG-52SHPacn
$160.65 CAD
Shipping calculated at checkout.
Out of stock

2.4/5GHz software selectable AP/Backbone/CPE with AC support, high TX power, N-male connector, Omni antenna included

Now with 802.11ac support, a Gigabit Ethernet port and a selectable wireless band (2.4GHz or 5GHz, up to 80 MHz wide channel). The new Gigabit port will help you utilize the full benefit of 802.11ac high speed wireless.

The Metal 52 ac supports 2.4GHz, 5GHz and all the legacy wireless modes as well (802.11 b/g/n for 2.4GHz and 802.11 a/n/ac for 5GHz).
Metal 52 ac
  • Metal 52 ac
  • Metal 52 ac
  • Metal 52 ac

We have two versions available.

- RBMetalG-52SHPacn-US (USA) is factory locked for 2412-2462MHz, 5170-5250MHz and 5725-5835MHz frequencies. This lock can not be removed.

- RBMetalG-52SHPacn (International) supports 2412-2484MHz and 5150MHz-5875MHz range (Specific frequency range can be limited by country regulations).

Specification

Specifications

  • Product codeRBMetalG-52SHPacn
  • Suggested price$119.00
  • ArchitectureMIPSBE
  • CPUQCA9556
  • CPU core count1
  • CPU nominal frequency720 MHz
  • Dimensions215x60x38mm
  • RouterOS license4
  • Operating SystemRouterOS
  • Size of RAM64 MB
  • Storage size16 MB
  • Storage typeFLASH
  • MTBFApproximately 200'000 hours at 25C
  • Tested ambient temperature-40°C to 70°C

Powering

  • Number of DC inputs1 (PoE-IN)
  • Max power consumption11 W
  • PoE inPassive PoE
  • Cooling typePassive
  • PoE in input Voltage10-30 V

Wireless specifications

  • Wireless 2.4 GHz/5 GHz Max data rate433 Mbit/s
  • Wireless 2.4 GHz/5 GHz Number of chains1
  • Wireless 2.4 GHz/5 GHz standards802.11a/n/ac, 802.11b/g/n
  • Antenna gain dBi for 2.4 GHz/5 GHz6
  • Wireless 2.4 GHz/5 GHz chip modelQCA9889
  • Wireless 2.4 GHz/5 GHz generationWi-Fi 5

Ethernet

  • 10/100/1000 Ethernet ports1

Other

  • PCB temperature monitorYes
  • Voltage MonitorYes
  • BeeperYes

Certification & Approvals

  • CertificationCE, FCC, IC, EAC, ROHS
  • IPIP55

Included parts24V 0.8A power adapterAngled N connectorMetal rings (two)6dBi / 8dBi omni antennaGigabit PoE injectorNoteThe device has an operating system preinstalled and licensed. No separate purchase is necessary and the product is ready to use. The device includes free software updates for the life of the product or a minimum of 5 years starting from date of purchase.
