Specification
Specifications
- Product codeCCR2116-12G-4S+
- Suggested price$995.00
- ArchitectureARM 64bit
- CPUAL73400
- CPU core count16
- CPU nominal frequency2000 MHz
- CPU Threads count16
- Switch chip model98DX3255
- Dimensions443 x 199 x 44 mm
- RouterOS license6
- Operating SystemRouterOS v7
- Size of RAM16 GB
- Storage size128 MB
- Storage typeNAND
- MTBFApproximately 200'000 hours at 25C
- Tested ambient temperature-20°C to 60°C
Powering
- Number of AC inputs2
- AC input range100-240
- Number of PSU slots2
- Frequency (Hz)47-63
- Max power consumption83 W
- Max power consumption without attachments60 W
- Cooling type4 fans
Ethernet
- 10/100/1000 Ethernet ports13
Fiber
- SFP+ ports4
Peripherals
- Serial console portRJ45
- Number of USB ports1
- Number of M.2 slots1
Other
- CPU temperature monitorYes
- PCB temperature monitorYes
- Voltage MonitorYes
- Mode buttonYes
Certification & Approvals
- CertificationCE, EAC, ROHS
Included partsIEC cordIEC cordRackmount bracket whiteK-57 kitNoteThe device has an operating system preinstalled and licensed. No separate purchase is necessary and the product is ready to use. The device includes free software updates for the life of the product or a minimum of 5 years starting from date of purchase.
