CRS106-1C-5S

CRS106-1C-5S

$83.30 CAD
CRS106-1C-5S

CRS106-1C-5S

CRS106-1C-5S
$83.30 CAD
Shipping calculated at checkout.
Out of stock

Smart Switch, 5x SFP cages, 1x Combo port (SFP or Gigabit Ethernet), 400MHz CPU, 128MB RAM, desktop case, RouterOS L5.

The Cloud Router Switch 106-1C-5S is a desktop size smart switch, equipped with one Gigabit Ethernet / SFP combo port and five 1.25Gbps SFP cages. The package includes a power supply. Powered by a 400MHz CPU and 128MB RAM, it runs RouterOS with a L5 license and supports 11- 30V power.

At $59 this product provides a market-leading solution for connecting up to six SFP devices.
CRS106-1C-5S
  • CRS106-1C-5S
  • CRS106-1C-5S

Specification

Specifications

  • Product codeCRS106-1C-5S
  • Suggested price$59.00
  • ArchitectureMIPSBE
  • CPUQCA8511
  • CPU core count1
  • CPU nominal frequency400 MHz
  • Switch chip modelQCA8511
  • Dimensions114 x 137 x 29mm
  • RouterOS license5
  • Operating SystemRouterOS
  • Size of RAM128 MB
  • Storage size16 MB
  • Storage typeFLASH
  • MTBFApproximately 100'000 hours at 25C
  • Tested ambient temperature-20°C to 70°C

Powering

  • Number of DC inputs2 (DC jack, PoE-IN)
  • DC jack input Voltage11-30 V
  • Max power consumption11 W
  • PoE inPassive PoE
  • Cooling typePassive
  • PoE in input Voltage11-30 V

Ethernet

  • Ethernet Combo ports1

Fiber

  • SFP ports5

Peripherals

  • Serial console portRJ45

Certification & Approvals

  • CertificationCE, EAC, ROHS
  • IPIP20

Included parts24V 0.8A power adapterNoteThe device has an operating system preinstalled and licensed. No separate purchase is necessary and the product is ready to use. The device includes free software updates for the life of the product or a minimum of 5 years starting from date of purchase.
