A versatile 100 Gigabit switch that offers speed, value, and diverse connectivity options. 2x 100 Gigabit QSFP28 ports, 8x 25 Gigabit SFP28 ports, dual hot-swap power supplies.

Remember our sensational 100 Gigabit switches – the CRS504 and CRS518? It’s time for another breathtaking addition to the MikroTik 100 Gigabit product family: the versatile CRS510-8XS-2XQ-IN!

This handy switch has two 100 Gigabit QSFP28 ports and eight 25 Gigabit SFP28 ports. This combination of ports guarantees a perfect fit in almost any setup or server room. Various direct attach cables, active optical cables, copper RJ45’s… CRS510 will keep everything connected! You’ll save time, money, and precious nerve cells with the backward compatibility. This unit supports all sorts of devices – 40 Gigabit, 25 Gigabit, 10 Gigabit, and even older Gigabit connections. And – speaking of nerve cells – we’ve kept the sysadmin’s emergency tool: the good old console port.
CRS510-8XS-2XQ-IN
  • CRS510-8XS-2XQ-IN
  • CRS510-8XS-2XQ-IN
  • CRS510-8XS-2XQ-IN

Another reason why we love the new CRS510 (and you will too!) is the performance. It can handle VLANs, ACL, MLAG, Jumbo frames, and so much more – even some L3 hardware offloading! The mighty Marvell Prestera switch chip dominates most tasks without blowing the power consumption up – only up to 27W (without attachments).

And when it comes to powering – CRS510 is a real joy to work with. It has dual hot-swap power supplies and three other powering options: PoE-in, DC jack, and a 2-pin terminal. No more unnecessary downtimes!

Specification

Specifications

  • Product codeCRS510-8XS-2XQ-IN
  • Suggested price$999.00
  • ArchitectureMIPSBE
  • CPUQCA9531
  • CPU core count1
  • CPU nominal frequency650 MHz
  • Switch chip model98DX4310
  • RouterOS license5
  • Operating SystemRouterOS v7
  • Size of RAM128 MB
  • Storage size32 MB
  • Storage typeFLASH
  • MTBFApproximately 200'000 hours at 25C
  • Tested ambient temperature-40°C to 70°C

Powering

  • Number of AC inputs2
  • AC input range100-240
  • Number of DC inputs3 (DC jack, PoE-IN, 2-pin terminal)
  • DC jack input Voltage36-57 V
  • Number of PSU slots2
  • 2-pin terminal input Voltage36-57 V
  • Frequency (Hz)47-63
  • Max power consumption45 W
  • Max power consumption without attachments27 W
  • PoE in802.3 bt
  • Cooling type2 fans
  • PoE in input Voltage42.5-57 V

Ethernet

  • 10/100 Ethernet ports1

Fiber

  • Number of 25G SFP28 ports8
  • Number of 100G QSFP28 ports2

Peripherals

  • Serial console portRJ45

Other

  • PCB temperature monitorYes
  • Voltage MonitorYes

Certification & Approvals

  • CertificationCE, EAC, ROHS
  • IP20

Included partsIEC cordIEC cordRack ears for CRS510K10 screw kitConnector plugNoteThe device has an operating system preinstalled and licensed. No separate purchase is necessary and the product is ready to use. The device includes free software updates for the life of the product or a minimum of 5 years starting from date of purchase.
