hAP ax²

hAP ax²

$139.75 CAD
hAP ax²

hAP ax²

C52iG-5HaxD2HaxD-TC
$139.75 CAD
Shipping calculated at checkout.
Out of stock

A Generation 6 version of the legendary hAP ac². With PoE-in and PoE-out, much faster wireless, more RAM, and a modern CPU. The smallest fully-fledged AX router on the market!

Wireless signal is now stronger than ever. Here are the two main ingredients of hAP ax’s success: a state-of-the-art dual-band, dual-chain 4-4.5 dBi radio, and the 802.11ax standard with Wave2 support. Let’s compare it to the previous generation: depending on your overall setup, that means up to 40% higher speed in the 5 GHz and up to 90% higher speed in the 2.4 GHz spectrum!
hAP ax²
  • hAP ax²
  • hAP ax²

The modern quad-core CPU running at 864 MHz combined with a solid GB of RAM packs a hefty punch when it comes to heavy operations like complex firewall rules, IPsec hardware encryption, using more threads or experimenting with the most advanced RouterOS features. And with the addition of WPA3 advanced encryption support, you’re safer than ever before.

Specification

Specifications

  • Product codeC52iG-5HaxD2HaxD-TC
  • Suggested price$99.00
  • ArchitectureARM 64bit
  • CPUIPQ-6010
  • CPU core count4
  • CPU nominal frequency864 MHz
  • CPU Threads count4
  • Switch chip modelIPQ-6010
  • RouterOS license4
  • Operating SystemRouterOS v7
  • Size of RAM1 GB
  • Storage size128 MB
  • Storage typeNAND
  • MTBFApproximately 100'000 hours at 25C
  • Tested ambient temperature-40°C to 50°C

Wireless capabilities

  • Wireless 2.4 GHz Max data rate574 Mbit/s
  • Wireless 2.4 GHz Number of chains2
  • Wireless 2.4 GHz standards802.11b/g/n/ax
  • Antenna gain dBi for 2.4 GHz4
  • Wireless 2.4 GHz chip modelQCN-5022
  • Wireless 2.4 GHz generationWi-Fi 6
  • Wireless 5 GHz Max data rate1200 Mbit/s
  • Wireless 5 GHz Number of chains2
  • Wireless 5 GHz standards802.11a/n/ac/ax
  • Antenna gain dBi for 5 GHz4.5
  • Wireless 5 GHz chip modelQCN-5052
  • Wireless 5 GHz generationWi-Fi 6
  • WiFi speedAX1800

Ethernet

  • 10/100/1000 Ethernet ports5
  • Number of 1G Ethernet ports with PoE-out1

Powering

  • Number of DC inputs2 (DC jack, PoE-IN)
  • DC jack input Voltage12-28 V
  • Max power consumption27 W
  • Max power consumption without attachments12 W
  • PoE inPassive PoE
  • Cooling typePassive
  • PoE in input Voltage18-28 V

PoE-out

  • PoE-out portsEther 1
  • PoE outPassive PoE
  • Low voltage PoE-Out current limit600 mA
  • Max total out (A)0.6 A
  • Total output current0.6
  • Total output power16.8W

Certification & Approvals

  • CertificationCE, FCC, IC, EAC, ROHS
  • IP20

Other

  • CPU temperature monitorYes
  • Mode buttonYes

Like the previous models, hAP ax² can be mounted vertically, horizontally, or even on the wall – without sacrificing the strong signal.

With so many products and features on the market, even an experienced user can become confused. So it’s time for a simple truth for a simple choice: you can’t go wrong with a hAP ax² in most homes.
