Specification
Specifications
- Product codeRB960PGS
- Suggested price$89.00
- ArchitectureMIPSBE
- CPUQCA9557
- CPU core count1
- CPU nominal frequency800 MHz
- Switch chip modelQCA8337
- RouterOS license4
- Operating SystemRouterOS
- Size of RAM128 MB
- Storage size16 MB
- Storage typeFLASH
- MTBFApproximately 100'000 hours at 25C
- Tested ambient temperature-40°C to 60°C
Powering
- Number of DC inputs2 (DC jack, PoE-IN)
- DC jack input Voltage12-57 V
- Max power consumption54 W
- Max power consumption without attachments6 W
- PoE inPassive PoE
- Cooling typePassive
- PoE in input Voltage12-57 V
PoE-out
- PoE-out portsEther2-Ether5
- PoE out802.3af/at
- Low voltage PoE-Out current limit1 A
- High voltage PoE-Out current limit450 mA
- Max total out (A)2 A
Ethernet
- 10/100/1000 Ethernet ports5
Fiber
- SFP ports1
Peripherals
- Number of USB ports1
- USB Power ResetYes
- USB slot typeUSB type A
- Max USB current (A)1
Other
- PCB temperature monitorYes
- Voltage MonitorYes
- BeeperYes
Certification & Approvals
- CertificationCE, EAC, ROHS
- IPIP20
Included parts24V 2.5A power adapterIEC cordNoteThe device has an operating system preinstalled and licensed. No separate purchase is necessary and the product is ready to use. The device includes free software updates for the life of the product or a minimum of 5 years starting from date of purchase.
