Whether you’re building a new system or adding LTE to an existing installation, KNOT Embedded LTE4 adapts easily. It’s easy to integrate, easy to deploy, and built to perform in harsh environments – from smart city deployments to industrial automation and mobile tracking.
Specification
Specifications
- Product codeEC25-EU&KNe
- Suggested price$79.00
- ArchitectureARM 32bit
- CPUCPU ARM 32-bit Cortex A7
- CPU core count1
- CPU nominal frequency800 MHz
- RouterOS license3
- Operating SystemRouterOS v7
- Size of RAM256 MB
- Storage size512 MB
- Storage typeNAND
- MTBFApproximately 100'000 hours at 25C
- Tested ambient temperature-40°C to 70°C
Powering
- Number of DC inputs2 (PoE-IN, USB-C)
- Max power consumption7 W
- Max power consumption without attachments7 W
- PoE in802.3af/at
- Cooling typePassive
- PoE in input Voltage12-57 V
- USB C input Voltage5 V
Mobile
- 2G CategoryClass12
- 2G bands3 (1800MHz)
8 (900MHz)
- 3G CategoryR8 (42.2Mbps Downlink, 5.76Mbps Uplink)
- 3G bands1 (2100MHz)
8 (900MHz)
- LTE Category4 (150Mbps Downlink, 50Mbps Uplink)
- MIMO DL2x2
- MIMO UL1x1
- LTE FDD bands1 (2100MHz)
3 (1800MHz)
7 (2600MHz)
8 (900 MHz)
20 (800MHz)
28A (700 MHz)
- LTE TDD bands38 (2600MHz)
40 (2300MHz)
41 (2500MHz)
- TAC86554604
Ethernet
- 10/100/1000 Ethernet ports1
- Number of 1G Ethernet ports with Reverse PoE (PoE-in)1
Peripherals
- Number of SIM slots1 Modem (Nano SIM)
Other
- CPU temperature monitorYes
- Bluetooth version5.1
- GPS RF connector typeSMA
- eSIMYes
Certification & Approvals
- CertificationCE, EAC, ROHS
- IP20
Included partsK-91 Fastening set5 V 0.8 A power adapterNoteThe device has an operating system preinstalled and licensed. No separate purchase is necessary and the product is ready to use. The device includes free software updates for the life of the product or a minimum of 5 years starting from date of purchase.
