LHG XL 5 ac

LHG XL 5 ac

$157.95 CAD
LHG XL 5 ac

LHG XL 5 ac

RBLHGG-5acD-XL
$157.95 CAD
Shipping calculated at checkout.
Out of stock

Dual chain Long Range 27dBi 5GHz CPE/Point-to-Point Integrated Antenna with AC support and Gigabit Ethernet

The LHG XL 5 ac is Long Range 5GHz 802.11ac wireless device with an integrated dual polarization 27 dBi grid antenna at a revolutionary price. It is perfect for point to point links or for use as a CPE at longer distances and supports Nv2 TDMA protocol.

The device includes one 10/100/1000 Mbit Ethernet port to fully utilize speeds that 802.11ac protocol provides.
LHG XL 5 ac
  • LHG XL 5 ac
  • LHG XL 5 ac
  • LHG XL 5 ac

- LHG XL 5 ac-US (USA) is factory locked for 5170-5250MHz and 5725-5835MHz frequencies. This lock can not be removed.

- LHG XL 5 ac (International) supports 5150MHz-5875MHz range (Specific frequency range can be limited by country regulations).

Shipped as a kit of 4 units (RBLHGG-5acD-XL4pack) - 4 antennas in a single box.

Specification

Specifications

  • Product codeRBLHGG-5acD-XL
  • Suggested price$117.00
  • ArchitectureARM 32bit
  • CPUIPQ-4018
  • CPU core count4
  • CPU nominal frequency488-896 (auto) MHz
  • CPU Threads count4
  • DimensionsØ 550 x 245 mm;
  • RouterOS license3
  • Operating SystemRouterOS
  • Size of RAM256 MB
  • Storage size16 MB
  • Storage typeFLASH
  • MTBFApproximately 200'000 hours at 25C
  • Tested ambient temperature-40°C to 70°C

Powering

  • Number of DC inputs1 (PoE-IN)
  • Max power consumption8 W
  • PoE inPassive PoE
  • Cooling typePassive
  • PoE in input Voltage10-30 V

Wireless specifications

  • Wireless 5 GHz Max data rate867 Mbit/s
  • Wireless 5 GHz Number of chains2
  • Wireless 5 GHz standards802.11a/n/ac
  • Antenna gain dBi for 5 GHz27
  • Wireless 5 GHz chip modelIPQ-4018
  • Wireless 5 GHz generationWi-Fi 5

Ethernet

  • 10/100/1000 Ethernet ports1

Certification & Approvals

  • CertificationCE, FCC, IC, EAC, ROHS
  • IPIP54

Included parts24V 0.38A power adapterMetal rings (two)Gigabit PoE injectorK-LHG kitNoteThe device has an operating system preinstalled and licensed. No separate purchase is necessary and the product is ready to use. The device includes free software updates for the life of the product or a minimum of 5 years starting from date of purchase.
