mANTBox 2 12s

mANTBox 2 12s

$139.77 CAD
mANTBox 2 12s

mANTBox 2 12s

RB911G-2HPnD-12S
$139.77 CAD
Shipping calculated at checkout.
Out of stock

2.4GHz 120 degree 12dBi dual polarization sector Integrated antenna with 600Mhz CPU, 64MB RAM, Gigabit Ethernet, PSU and PoE

mANTBox 2 12s is long range 12dbi 120 degrees integrated Base Station for 2.4 GHz.

The mANTBox is based on our new mANT sector antennas, but also has a wireless router built right in. Powered by the RB911 device, the mANTBox comes ready to use with everything included. The device uses a high speed 600 MHz CPU, comes with the Gigabit Ethernet port and has a built in 802.11 b/g/n wireless device with up to 30 dBm output power.
mANTBox 2 12s
  • mANTBox 2 12s
  • mANTBox 2 12s
  • mANTBox 2 12s

Specification

Specifications

  • Product codeRB911G-2HPnD-12S
  • Suggested price$99.00
  • ArchitectureMIPSBE
  • CPUAR9342
  • CPU core count1
  • CPU nominal frequency600 MHz
  • Dimensions140 x 348 x 82 mm
  • RouterOS license4
  • Operating SystemRouterOS
  • Size of RAM64 MB
  • Storage size128 MB
  • Storage typeNAND
  • MTBFApproximately 100'000 hours at 25C
  • Tested ambient temperature-40°C to 70°C

Powering

  • Number of DC inputs2 (DC jack, PoE-IN)
  • DC jack input Voltage8-30 V
  • Max power consumption11 W
  • PoE inPassive PoE
  • Cooling typePassive
  • PoE in input Voltage10-28 V

Wireless specifications

  • Wireless 2.4 GHz Max data rate300 Mbit/s
  • Wireless 2.4 GHz Number of chains2
  • Wireless 2.4 GHz standards802.11b/g/n
  • Antenna gain dBi for 2.4 GHz12
  • Wireless 2.4 GHz chip modelAR9342
  • Wireless 2.4 GHz generationWi-Fi 4

Ethernet

  • 10/100/1000 Ethernet ports1

Other

  • PCB temperature monitorYes
  • Voltage MonitorYes
  • BeeperYes

Certification & Approvals

  • CertificationCE, FCC, IC, EAC, ROHS
  • IPIP54

Included partsGigabit PoE injectorQMP24V 0.8A power adapterMetal ring (one)K-41 fastening setNoteThe device has an operating system preinstalled and licensed. No separate purchase is necessary and the product is ready to use. The device includes free software updates for the life of the product or a minimum of 5 years starting from date of purchase.
