netPower Lite 7R

netPower Lite 7R

$196.24 CAD
netPower Lite 7R

netPower Lite 7R

CSS610-1Gi-7R-2S+OUT
$196.24 CAD
Shipping calculated at checkout.
Out of stock

An outdoor reverse PoE switch with Gigabit Ethernet and 10G SFP+ ports.

With netPower Lite 7R switch you can forget about expensive GPON base stations and optical splitters. This switch is a part of our GPEN concept – aimed to bring the speed and versatility of fiber networking while using the advantages of Ethernet. It is an easy to deploy, low-cost way for any ISP to deliver the Internet to individual apartments.

With this switch you won’t have to worry about power issues, as there are many options. netPower Lite 7R has 7 reverse PoE ports. Depending on your setup, netPower can draw the necessary power even from a single client! Ethernet port 8 can power other PoE capable devices with the same voltage as applied to the unit. There is also a DC jack and a 2-pin terminal for alternative powering.

The outdoor enclosure allows you to install this switch in all kinds of environments – from damp attics to elevator shafts and different poles with hose clamps. netPower Lite 7R has a non-blocking throughput of 28 Gbps, switching capacity of 56 Gbps and forwarding rate of 41.7 Mpps.
netPower Lite 7R
  • netPower Lite 7R
  • netPower Lite 7R

Specification

Specifications

  • Product codeCSS610-1Gi-7R-2S+OUT
  • Suggested price$139.00
  • Switch chip model88E6193X
  • Dimensions304 x 212 x 71 mm
  • Operating SystemSwitchOS Lite
  • Storage size64 KB
  • Storage typeFLASH
  • MTBFApproximately 200'000 hours at 25C
  • Tested ambient temperature-40°C to 70°C

Powering

  • Number of DC inputs3 (DC jack, PoE-IN, 2-pin terminal)
  • DC jack input Voltage12-57 V
  • 2-pin terminal input Voltage12-57 V
  • Max power consumption29 W
  • Max power consumption without attachments7 W
  • PoE inPassive PoE
  • Cooling typePassive
  • PoE in input Voltage12-57 V

PoE-out

  • PoE-out portsEther8
  • PoE outPassive PoE
  • Low voltage PoE-Out current limit600 mA
  • High voltage PoE-Out current limit450 mA
  • Max total out (A)600 mA

Ethernet

  • 10/100/1000 Ethernet ports8
  • Number of 1G Ethernet ports with Reverse PoE (PoE-in)7
  • Number of 1G Ethernet ports with PoE-out1

Fiber

  • SFP+ ports2

Certification & Approvals

  • CertificationCE, EAC, ROHS
  • IPIP54

Included partsK-66 fastening setHose clamp 2NoteThe device has an operating system preinstalled and licensed. No separate purchase is necessary and the product is ready to use. The device includes free software updates for the life of the product or a minimum of 5 years starting from date of purchase.
