OmniTIK 5 PoE ac

OmniTIK 5 PoE ac

$187.65 CAD
OmniTIK 5 PoE ac

OmniTIK 5 PoE ac

RBOmniTikPG-5HacD
$187.65 CAD
Shipping calculated at checkout.
Out of stock

7.5dBi Integrated AP, 5GHz Dual chain with 802.11ac support, 5x Gigabit Ethernet ports with PoE-out

We are glad to introduce a significant upgrade to our popular OmniTIK 5GHz access points!

OmniTIK 5 PoE ac features five Gigabit Ethernet ports and support for 802.11ac. It’s equipped with a powerful 720MHz CPU, 128MB RAM, high power 802.11a/n/ac Dual Chain wireless (support for AC as well as backwards compatible with regular 802.11a/n CPE) and comes with a new design weatherproof outdoor enclosure, two integrated 7.5dBi 5GHz omni antennas, a power supply, a PoE injector and a mounting kit.

It also supports passive or standard 802.3at/af PoE input/output. Ethernet ports 2-5 can power other PoE capable devices with the same voltage as applied to the unit. Less power adapters and cables to worry about! It can power af/at mode B (4,5+)(7,8-) compatible devices, if 48-57 input voltage is used.
OmniTIK 5 PoE ac
  • OmniTIK 5 PoE ac
  • OmniTIK 5 PoE ac
  • OmniTIK 5 PoE ac
  • OmniTIK 5 PoE ac

- OmniTIK 5 PoE ac US (USA) is factory locked for 5170-5250MHz and 5725-5835MHz frequencies. This lock can not be removed.

- OmniTIK 5 PoE ac (International) supports 5150MHz-5875MHz range (Specific frequency range can be limited by country regulations).

Specification

Specifications

  • Product codeRBOmniTikPG-5HacD
  • Suggested price$139.00
  • ArchitectureMIPSBE
  • CPUQCA9557
  • CPU core count1
  • CPU nominal frequency720 MHz
  • Switch chip modelQCA8337
  • Dimensions416 x 129 x 58 mm
  • RouterOS license4
  • Operating SystemRouterOS
  • Size of RAM128 MB
  • Storage size16 MB
  • Storage typeFLASH
  • MTBFApproximately 200'000 hours at 25C
  • Tested ambient temperature-40°C to 70°C

Powering

  • Number of DC inputs1 (PoE-IN)
  • Max power consumption66 W
  • Max power consumption without attachments18 W
  • PoE inPassive PoE
  • Cooling typePassive
  • PoE in input Voltage12-57 V

PoE-out

  • PoE-out portsEther2-Ether5
  • PoE out802.3af/at
  • Low voltage PoE-Out current limit1 A
  • High voltage PoE-Out current limit450 mA
  • Max total out (A)2 A

Wireless specifications

  • Wireless 5 GHz Max data rate867 Mbit/s
  • Wireless 5 GHz Number of chains2
  • Wireless 5 GHz standards802.11a/n/ac
  • Antenna gain dBi for 5 GHz7.5
  • Wireless 5 GHz chip modelQCA9892
  • Wireless 5 GHz generationWi-Fi 5

Ethernet

  • 10/100/1000 Ethernet ports5

Peripherals

  • Number of USB ports1
  • USB Power ResetYes
  • USB slot typeUSB type A
  • Max USB current (A)1

Other

  • PCB temperature monitorYes
  • Voltage MonitorYes
  • BeeperYes

Certification & Approvals

  • CertificationCE, FCC, IC, EAC, ROHS
  • IPIP54

Included partsPole mounting bracketMetal ring (one)Gigabit PoE injectorIEC cord28V 2.57A power adapterNoteThe device has an operating system preinstalled and licensed. No separate purchase is necessary and the product is ready to use. The device includes free software updates for the life of the product or a minimum of 5 years starting from date of purchase.
