Specification
Specifications
- Product codeRB1100Dx4
- Suggested price$385.00
- ArchitectureARM 32bit
- CPUAL21400
- CPU core count4
- CPU nominal frequency1.4 GHz
- CPU Threads count4
- Switch chip modelRTL8367
- Dimensions443 x 148 x 44 mm
- RouterOS license6
- Operating SystemRouterOS
- Size of RAM1 GB
- Storage size128 MB
- Storage typeNAND
- MTBFApproximately 200'000 hours at 25C
- Tested ambient temperature-40°C to 70°C
Powering
- Number of AC inputs2
- Number of DC inputs2 (PoE-IN, 2-pin terminal)
- 2-pin terminal input Voltage-48, 20-57 V
- Max power consumption33 W
- Max power consumption without attachments25 W
- PoE in802.3af/at
- Cooling typePassive
- PoE in input Voltage20-57 V
Ethernet
- 10/100/1000 Ethernet ports13
Peripherals
- Extended storage60GB M.2 SSD included
- Memory card typemicroSD
- Memory Cards1
- SATA ports2x SATA3
- Serial console portRS232
- Number of M.2 slots2
Other
- Current MonitorYes
- PCB temperature monitorYes
- Voltage MonitorYes
- BeeperYes
Certification & Approvals
- CertificationCE, EAC, ROHS
- IPIP20
Included partsSATA cablesRack earsM.2 SSD 60GB2x IEC cordsK-57 kitNoteThe device has an operating system preinstalled and licensed. No separate purchase is necessary and the product is ready to use. The device includes free software updates for the life of the product or a minimum of 5 years starting from date of purchase.
